| Display |
| Diagonal Size |
65 inch LED Backlight |
| Backlight |
LED |
| Panel |
VA |
| Resolution |
3840 × 2160 @60 Hz |
| Color |
1.07B |
| Visual Angle |
178° (H) / 178° (V) |
| Response Time |
6 ms |
| Contrast |
5000:1（Typ.） |
| Brightness |
400 cd/m² with Brightness sensor |
| Dot Pitch (H x V) |
0.124 × 0.372mm |
| Built-In System |
| Operation System |
Android 12.0, OTA upgrade to Android 13.0 |
| Processor |
Quad-core Cortex-A76 × 4(2.4GHz) and quad-core Cortex-A55 × 4(1.8GHz) |
| Memory |
8 GB |
| Built-In Storage |
128 GB |
| HDCP Version |
2.0 |
| Touch Resolution |
32768 × 32768 |
| Touch |
| Type |
Infrared Touch Screen |
| Touch Point |
Max 45 point multi-touch |
| Touch Response Time |
< 8 ms |
| Touch Precision |
± 1 mm (≥ 90% touching area) |
| Camera |
| Pixel |
8 MP (48MP for photos) |
| Camera Function |
Support intelligent switching between Android system, OPS, and PC |
| Field Angle |
120°(diagonal), 110°(horizontal), 75°(vertical) |
| Distortion |
≤2.5% |
| Camera Resolution Ratio |
Up to 4K |
| Microphone |
| Specification |
Omni-directional 8-array layout |
| Mic Function |
Echo reduction and smart noise cancellation |
| Voice Distance |
12 m |
| Sampling Rate |
32 K |
| Mic Sampling Rate |
16 bit |
| Interface |
| Input Interface |
HDMI In × 3, VGA In x 1, DP In x 1, Audio In x 1 |
| Output Interface |
HDMI Out x 1, Audio Out x 1, SPDIF Out x1 |
| Control Interface |
TOUCH-USB × 3, RS232 × 1 |
| Power |
| Power Consumption |
≤ 140 W (Average) |
| Power Requirement |
0.5 W |
| Working Environment |
| Operating Temperature |
0 ºC to 40 ºC |
| Operating Humidity |
10% to 90% RH |
| General |
| Dimension (W x H x D) |
1491.9 x 82.5 x 910.6 mm |
